Maximize Efficiency with the Cat5e Shielded Short Body Modular Plug
In modern networking, especially in industrial automation and dense data centers, space and signal integrity are equally critical. Our Cat5e shielded short body modular plug is the ultimate solution for engineers who refuse to compromise on either. By integrating a high-performance metal shield into a compact, short-body housing, this connector allows for cleaner cable management and robust protection against external noise.
Superior EMI Protection for Harsh Environments
Electromagnetic Interference (EMI) can lead to packet loss and network downtime. This Cat5e shielded short body modular plug features a premium nickel-plated copper alloy shell that provides a continuous ground path. Whether you are installing equipment near high-voltage lines or in a crowded server rack, the shielding ensures your data remains secure and uninterrupted. For more information on shielding standards, you can refer to the ANSI/TIA industry portal
Technical Specifications (Mobile-Optimized Table)
| Feature | Specification |
| Model Type | Cat5e Shielded Short Body Modular Plug |
| Interface | 8P8C (RJ45) |
| Shielding Material | Nickel-Plated Copper Alloy |
| Contact Plating | 50μ” Gold over Nickel |
| Housing Material | Clear Polycarbonate (UL 94V-2) |
| Cable Support | 24 – 26 AWG Shielded (STP) |
| Transmission Speed | Up to 1000 Mbps (Gigabit) |
| Operating Temp | -40°C to +85°C |
| Certifications | RoHS, REACH, UL Compliant |
The Advantage of the Short Body Design
Traditional connectors often struggle in tight wall plates or behind slim-line networking gear. The Cat5e shielded short body modular plug reduces the overall length of the connector, allowing for a much tighter bend radius. This reduces mechanical stress on the internal wire pairs, which is a common cause of performance degradation over time. Using a Cat5e shielded short body modular plug ensures that your high-density installations look professional and perform reliably.
Engineered for Longevity: 50μ” Gold Plating
Not all gold plating is created equal. Many competitors use thin “flash” plating that wears off quickly. Our Cat5e shielded short body modular plug utilizes a true 50 micro-inch gold layer on phosphor bronze contacts. This ensures the best possible electrical connection and prevents the corrosion that occurs in humid or industrial settings. Even after hundreds of insertion cycles, the Cat5e shielded short body modular plug maintains its low contact resistance.
Why Choose Our Connectivity Solutions?
As a specialized manufacturer, we focus on the fine details that matter to professionals. Every Cat5e shielded short body modular plug undergoes rigorous quality control, including a salt spray test for the shielding and a resilience test for the locking latch. We also recommend pairing this with our shielded Cat5e cables for a complete end-to-end shielded solution. By investing in our professional-grade connectors, you are ensuring the long-term uptime and reliability of your entire network infrastructure.
