Revolutionize Your Installation: The Pass-Through Advantage
Networking professionals know that the most time-consuming part of any installation is ensuring the wire sequence is correct before crimping. Our Cat6 Pass-Through RJ45 Connector eliminates the guesswork. By allowing the individual conductors to pass entirely through the connector body, you can visually verify the T568A or T568B sequence with 100% accuracy. This “Feed-Thru” technology significantly reduces wasted connectors and minimizes the need for re-termination, saving you time and labor costs on the job site.
Optimized for Cat6 Performance
While standard Cat6 plugs often use a staggered (up/down) layout, our Single-Row Pass-Through version is designed for specific cable geometries. It accommodates insulated wire diameters up to 1.1mm, making it the ideal choice for high-quality 23AWG and 24AWG unshielded twisted pair (UTP) cables. The precision-engineered internal channels keep the wires tightly aligned, reducing Near-End Crosstalk (NEXT) and ensuring your network hits true Gigabit speeds.
Uncompromising Build Quality
At HXPLUG, we believe that even a small component deserves world-class engineering. We use only 100% virgin Polycarbonate (PC). Unlike cheap, recycled plastics that turn yellow or brittle, our connectors remain crystal clear and highly resilient. The locking tab (the “clip”) is tested to withstand over 180-degree bends without snapping, ensuring a secure connection in high-density patch panels or wall jacks.
🛠️ Technical Specifications (Mobile-Optimized)
| Feature | Technical Details |
| Model | Cat6 UTP Pass-Through |
| Structure | 8P8C Single-Row |
| Max Insulated OD | 1.10 mm |
| Gold Plating | 50 micro-inches (Pure Gold) |
| Contact Blade | 3-Prong (Fits Solid & Stranded) |
| Flammability Rating | UL 94V-2 / 94V-0 |
| Transmission Rate | 1000Mbps (1Gbps) |
| Standard | RoHS, REACH, ISO9001 |
Maximum Signal Integrity: 50μ” Gold Contacts
In the B2B world, reliability is everything. Many suppliers claim “gold plating” but only provide a thin flash that wears off within months. HXPLUG’s connectors feature a thick 50 micro-inch gold layer over phosphor bronze contacts. This isn’t just for show; it provides an exceptionally low-resistance contact point that resists oxidation even in humid environments. The 3-prong design ensures a more stable “bite” into the copper wire, whether you are using solid core horizontal cabling or flexible stranded patch cords.
Why Professional Installers Trust HXPLUG?
Sourcing from HXPLUG means you are dealing directly with a manufacturing-focused partner. We understand the nuances of the global telecommunications market. Our Cat6 pass-through plugs are designed to be compatible with almost all standard pass-through crimping tools. Every batch is subjected to rigorous QC, including salt spray testing and insertion force testing, to ensure that your inventory meets the high standards your clients expect.
Looking for the right tools? Pair these connectors with our Professional RJ45 Crimping Tool for a perfect termination every time. Need a shielded version? View our Shielded Cat6A Pass-Through Plugs.
Q: Do these work with standard crimping tools? A: To take advantage of the pass-through feature (cutting the wires flush), you should use a dedicated Pass-Through Crimping Tool. However, they can be used with standard tools if the wires are pre-trimmed.
Q: What is the maximum wire diameter these can hold? A: Our Cat6 single-row pass-through supports insulated conductors with an outer diameter (OD) up to 1.10mm.
Q: Are these 50 micron gold plated? A: Yes, we use genuine 50μ” gold plating to ensure the highest conductivity and durability in the industry.
