“This RJ11-6P4C Modular Plug is the professional solution for standard telephone and voice networking systems, ensuring stable connectivity and long-term durability for global telecommunications infrastructure.”
The Reliable Choice for Global Telecommunications
Our RJ11-6P4C Modular Plug is specifically engineered to provide seamless connectivity for standard telephone systems, ADSL lines, and fax machines. As a specialized manufacturer with over 20 years of experience, we ensure that every RJ11-6P4C modular plug meets rigorous international standards for both mechanical durability and electrical performance.
Key Features of Our 6P4C Telephone Connector:
-
Precision Engineering: Designed with a 6-position, 4-contact configuration to fit all standard RJ11 interfaces accurately.
-
High-Grade Material: We use 100% new, eco-friendly Polycarbonate (PC) for the housing, ensuring high transparency and superior flame retardancy.
-
Enhanced Conductivity: Available with gold plating thickness ranging from 3u” to 50u”, ensuring stable signal transmission even in high-frequency usage.
-
Universal Compatibility: This RJ11-6P4C modular plug is compatible with both 24-26 AWG stranded and solid cables, making it ideal for diverse installation needs.
Technical Specification Table
| Component | Material & Performance |
| Model Number | HX-RJ11-6P4C |
| Contact Blade | Phosphor Bronze with 3-Prong design |
| Gold Plating | 3u”, 6u”, 15u”, 30u”, 50u” (Customizable) |
| Housing Color | Clear / Transparent (Custom colors available) |
| Standard Compliance | RoHS, REACH, ISO 9001 Certified |
| Insertion Life | Over 750 mating cycles |
Frequently Asked Questions (FAQ)
Q1: What is the difference between 6P2C and 6P4C RJ11 connectors?
While both use the same 6-position housing, the RJ11-6P4C modular plug uses 4 contacts, supporting two telephone lines. The 6P2C version only uses 2 contacts for a single line. Our 6P4C version offers better versatility.
Q2: Why is gold plating thickness important for the RJ11-6P4C modular plug?
Gold plating prevents oxidation. For industrial use, we recommend 50u” gold plating, which provides the highest level of corrosion resistance for the RJ11-6P4C modular plug.
Q3: Does your factory support OEM or custom branding?
Yes, Huaxiang Electronics is a professional OEM/ODM provider. We can customize packaging and add your brand logo for bulk orders of the RJ11-6P4C modular plug.
Installation Guide for RJ11-6P4C Modular Plug
-
Prepare the Cable: Strip 15mm of the outer jacket.
-
Arrange the Wires: Follow the color code for a standard RJ11-6P4C modular plug installation.
-
Trim & Insert: Cut wires to 10mm and slide them into the RJ11-6P4C modular plug until they reach the end.
-
Crimp & Test: Use a professional tool to crimp the RJ11-6P4C modular plug and verify with a tester.
Storage and Maintenance for RJ11-6P4C Modular Plugs
Store your RJ11-6P4C modular plug in a cool, dry environment (humidity <60%) to prevent oxidation. Avoid direct UV exposure to maintain housing transparency.
