Industrial-Grade Shielded 10P10C Connector (RJ50) for Reliable Data Transmission
When it comes to specialized industrial communications, standard networking plugs simply do not provide the necessary pinout density or signal integrity. The premium shielded 10P10C connector (widely known in the industry as the RJ50 connector) engineered by HXPLUG is the ultimate solution for complex data transmission tasks. Designed with 10 positions and 10 contacts, this 10 pin modular connector expands the capabilities of traditional networking hardware, allowing for dedicated ground lines, power delivery, and multiple serial data streams within a single compact interface.
Whether you are manufacturing custom barcode scanner cables, setting up uninterruptible power supply (UPS) management systems, or integrating proprietary medical diagnostic equipment, our shielded 10P10C modular plug ensures zero signal loss and maximum physical durability in demanding environments.
Advanced Shielding for EMI/RFI Protection
Industrial settings are often saturated with electromagnetic interference (EMI) and radio frequency interference (RFI) generated by heavy machinery, motors, and high-voltage power lines. To combat this, the HXPLUG 10P10C connector features a robust, full-metal shielding shell made from high-quality brass and coated with a corrosion-resistant nickel finish. This 360-degree shielding encapsulates the internal contacts, effectively blocking external noise and ensuring that your serial data protocols run smoothly without packet loss or signal degradation.
50µ” Gold-Plated Contacts for Maximum Longevity
The core of any reliable 10 pin modular connector lies in its contact pins. Unlike standard consumer-grade plugs that use 3µ” or 6µ” gold flashing, our industrial-grade RJ50 connectors are equipped with 50 micro-inches (50µ”) of pure gold plating over phosphor bronze contacts. This extremely thick gold layer provides three critical B2B advantages:
- Exceptional Mating Cycles: Guaranteed to withstand over 1,200 insertion and extraction cycles without wearing down the conductive surface.
- Oxidation & Corrosion Resistance: Prevents rust and contact resistance buildup, even in highly humid or chemically harsh industrial environments.
- Superior Conductivity: Ensures ultra-low contact resistance for both low-voltage data signals and Power over Ethernet (PoE) or custom power delivery applications.
Ergonomic and Flame-Retardant Polycarbonate Housing
Safety and physical integrity are paramount at HXPLUG. The transparent housing of our 10P10C connector is injection-molded from premium Polycarbonate (PC) material, strictly adhering to UL94V-0 or UL94V-2 flammability standards. The three-prong contact blade design provides a strong, piercing grip that securely bites into both solid and stranded copper wires (24 AWG to 26 AWG), preventing cable pull-outs and internal disconnections. The flexible yet sturdy latch is rigorously bend-tested to ensure it won’t snap off during installation or maintenance.
Technical Specifications (10P10C / RJ50)
| Parameter | Specification / Material |
|---|---|
| Connector Type | 10P10C (10 Position, 10 Contact), Shielded |
| Common Name | RJ50 Connector / 10 Pin Modular Plug |
| Housing Material | Polycarbonate (PC), UL94V-0 / UL94V-2 Rated |
| Shielding Material | Brass with Nickel Plating |
| Contact Material | Phosphor Bronze |
| Plating Thickness | 50µ” (Micro-inches) Gold Plating |
| Wire Compatibility | 24 AWG – 26 AWG (Solid & Stranded Wire) |
| Mating Life | ≥ 1,200 Cycles |
| Current Rating | 1.5 Amps (Maximum) |
| Voltage Rating | 150 Volts AC (Maximum) |
| Operating Temperature | -40°C to +85°C |
Primary Industry Applications
Because the 10P10C connector offers two more pins than standard 8P8C (RJ45) plugs, it is highly sought after for specialized communication links. Common applications include:
- Point of Sale (POS) & Scanners: Used extensively in Motorola, Symbol, and Zebra barcode scanners for serial data transfer and direct power supply.
- Power Equipment Management: The preferred interface for APC UPS (Uninterruptible Power Supply) communication ports to monitor battery health and trigger automated shutdowns.
- Automotive & Medical Diagnostics: Utilized in proprietary scanning tools where multiple signal protocols need to be transmitted simultaneously in a small form factor.
- Custom Control Systems: Ideal for factory automation setups, servo motor controllers, and customized RS-232 / RS-485 serial communication patch cables.
Why Partner with HXPLUG for Network Connectivity?
As a leading supplier in the telecommunications and networking hardware sector, HXPLUG understands that component failure is not an option for B2B manufacturers and system integrators. Our shielded 10P10C modular plugs undergo rigorous automated optical inspection (AOI) and electrical continuity testing before leaving the factory. We offer highly competitive wholesale pricing, flexible MOQ (Minimum Order Quantity), and robust OEM/ODM customization services. Whether you need custom packaging, specific gold-plating thicknesses (from flash gold to 50µ”), or specialized housing materials, our engineering team is ready to support your supply chain.
Contact HXPLUG today to request free samples and a detailed wholesale quotation for your 10 pin modular connector requirements.
