The Ultimate Solution for 23AWG Cat6 Shielded Cables
In modern network infrastructure, Category 6 cables are becoming thicker to support higher frequencies and Power over Ethernet (PoE) applications. Standard RJ45 connectors often have wire holes that are too small (0.9 mm or less), making it impossible to insert 23AWG wires with thick insulation. Our Cat6 Shielded RJ45 Connector with 1.1 mm Large Wire Hole is the definitive answer to this challenge. By expanding the internal channels, this plug allows for a smooth, “push-in” installation without the need to strip away essential insulation, maintaining the cable’s physical and electrical integrity.
High-Performance Staggered Double-Row Architecture
What makes this connector truly “Cat6” is its staggered double-row internal geometry. In a traditional flat-row configuration, the wires are crowded together, leading to significant signal leakage. Our staggered 4-up/4-down design increases the physical distance between the conductors at the most critical point—the termination. This geometric separation effectively cancels out capacitive coupling, ensuring that your network passes rigorous Fluke testing and maintains stable 1000Mbps speeds even in high-density environments.
Technical Specifications (Parameter Table)
| Feature | Specification Details |
| Product Model | HX-C6-STP-11-STG |
| Category Rating | Cat6 (Category 6) |
| Shielding Type | STP / FTP / SFTP (Shielded) |
| Wire Hole Diameter | 1.0 mm – 1.1 mm (Large Hole) |
| Internal Design | Staggered Double-Row (4-Up / 4-Down) |
| Contact Plating | 50μ” Gold over Nickel |
| Shell Material | Nickel-Plated Copper Alloy |
| Housing Material | UL 94V-2/V-0 Polycarbonate |
| Wire Compatibility | 23AWG – 24AWG Solid/Stranded |
| Data Rate | Up to 1 Gbps |
| Bandwidth | 250 MHz |
Superior Shielding for Industrial Environments
Electronic noise is everywhere, especially in data centers and industrial facilities. The Cat6 Shielded RJ45 Connector is encased in a robust nickel-plated metal shell. This shell acts as a continuous ground from the cable’s drain wire to the network equipment, effectively draining away interference. This prevents “packet loss” and “latency jitter” caused by nearby power lines or high-frequency equipment.
Industrial-Grade 50μ” Gold Plating
Conductivity is only as good as the plating. We use 50 micro-inch gold plating—the highest industrial standard—over high-purity phosphor bronze terminals. This ensures that even after 750+ mating cycles, the contact point remains free from corrosion. This is particularly vital for PoE+ and PoE++ applications, where high-quality contact is required to prevent localized heating at the connection point.
Installation Guidance
For the best results, use a shielded RJ45 crimping tool designed for staggered plugs. Ensure the cable’s drain wire makes solid contact with the metal tail of the connector. The large 1.1 mm hole allows you to push the cable jacket deep into the plug, providing superior strain relief and mechanical strength.
